Digital Images Collection
Clodock Mill c.1998
 | 1. Clodock mill building with the external breast-shot waterwheel | | |  | 2. The primary gears, including the pit wheel, spur wheel and stone nuts | |
 | 3. Detail of the unusual tentering mechanism, with toothed gears and screw acting on a pivoting steel arm | | |  | 4. The lay shaft pinion and the crown wheel, on the stone floor | |
 | 5. The upright shaft, crown wheel and lay shaft, between the two pairs of millstones | | |  | 6. One of the two pairs of millstones, fully furnished for milling | |
 | 7. Detail of the millstone furniture, showing the horse, hopper, grain chute and damsel | | |  | 8. The stone floor at Clodock mill, showing the arrangement of the upright and lay shafts | |
 | 9. The sack hoist on the bin floor | | |  | 10. The sack hoist | |
 | 11. Detail of the sack hoist mechanism | | | |
| | |
Ref: rs_dic_00041
